Used for general aluminum, high strength rare earth aluminum and alloy aluminum.
Horizontal serial structure. Dual motor drive. Fast die change design.
High-precision grinding helical gear drive. High efficiency, low noise.
Drawing capstan was combined design.
Fully immersed lubrication cooling to ensure the quality of the wire.
Take up use for: Double spooler and Basket coiler. High automation and high efficiency.
Technical Specification ：
Recommended match:
1. Online annealer (online annealing)
2. Double Spooler (applicable to the normal stranding process of cable conductors)
3. Basket Coiler (applicable to cable conductor stranding process. Used in enameled wire bus production.)
|
Machine type |
HT.SD450A.01.13 |
HT.SD450A.01.11 |
HT.SD450A.01.09 |
|
|
Material |
Al、Al Alloy |
|||
|
Machine speed |
Max.1500m/min |
|||
|
No. of wire |
1/2 |
|||
|
Inlet dia. |
9.50mm |
|||
|
Outlet dia. |
1.70mm-4.50mm |
2.10mm-4.50mm |
2.80mm-4.50mm |
|
|
No. of dies |
13 |
11 |
9 |
|
|
Capstan dia. |
450mm |
|||
|
Finished capstan dia. |
450mm |
|||
|
Die change system |
Fast die change system |
|||
|
Control method |
DC/AC |
|||
|
Drive method |
Two motors |
|||
