FRAME : monolithic, made of profiles andelectrowelded/normalized steel plates.The supports bearing the rotor spindles are placed sideways. The frame is secured to the floor by means of screw anchors (included in our supply) with adjustable dowels for levelling.
ROTOR: consists of 2 spindles connected through 2 bows. Spindles are mounted on high precision bearings, which are grease lubricated through points joined outside, to allow lubrication even if machine is running, and are placed on cast iron removable housings. The motion is transmitted to the spindles by a transversal transmission shaft via pulleys and toothed belts.
Technical Specification ：
Mainly use for material: Bare copper wire, tin wire, silver wire.
Machine type
HT.DMB630.01
HT.DMB800.01
HT.DMB1000.01
HT.DMB1250.01
HT.TMB630.01
HT.TMB800.01
HT.TMB1000.01
HT.TMB1250.01
Strand cross-section
0.15-6.00mm2
0.75-16.00mm2
1.5-25.00mm2
6.00-50.00mm2
Wire dia.
0.15-0.68mm
0.25-1.00mm
0.50-1.78mm
0.50-2.80mm
Pitch range
6.00-62.0mm
17.0-180.0mm
20.0-200.0mm
35.00-280.0mm
Machine speed
Max.3000RPM
(6000Twist/min)
Max.2200RPM
(4400Twist/min)
Max.1000RPM
(2000Twist/min)
Max.800RPM
(1600Twist/min)
Pitch change
Change pitch gears and electronic pitches
Bobbin size
500mm&630mm
630mm&800mm
630mm-1000mm
800mm-1250mm
